Program
Number
Program Name/Description Assigned Data
22-02-01 * Incoming Call trunk Setup
Assign all PRI trunks as an incoming type of DDI Mode Switching (set-
ting data 8).
This program is per trunk and per day/night mode, which there are 8
day/night modes. It is recommended that all 8 day/night modes be set
as DDI.
0 = Normal
1 = VRS
2 = DISA
3 = DID
4 = DIL
5 = E&M Tie Line
6 = Delay VRS
7 = ANI/DNIS
8 = DID (DDI) Mode Switching
(default = 0)
14-05-01 Trunk Group Setup
Assign all PRI trunks, including the D-Channel, to a valid trunk group.
Do not assign any used PRI trunks in trunk group 0.
0 ~ 25
(default = 1)
22-09-01 Expected number of Digits
Enter the number of digits, per the trunk group assigned in PRG
14-05, that the Telco will be sending to the SL1100 as DID's.
The SL1100 will analyze the digits received from the Telco starting
from the last digits working towards the first digits.
Example:
If the SL1100 was set to receive 4 digits and the Telco sent 10 digits
(214-555-1000) the SL1100 would route off of the last 4 digits re-
ceived (1000).
1 ~ 8
(default = 4)
22-17-01 * DDI Translation Table
Enter the digits received from the Telco that are going to be transla-
ted.
The amount of digits entered should be equal to the setting assigned
in PRG 22-09-01.
Maximum of 8 digits (0 ~ 9,
, #)
500 tables (entries) max
(default = Not Assigned)
22-17-04 * Dial In Conversion table Number
Used to assign a DID translation table to one of the 500 entries in
PRG 22-17-01 per day night mode.
This can be done automatically following the system day/night modes
or manually via a function key.
1 ~ 800 (These are the table entries
in PRG 22-11.)
(default = Not Assigned)
22-11-01 Received Number
DO NOT assign anything here for the tables specified in PRG
22-17-04.
This must be left blank or the DDI routing will not work.
Maximum of 8 digits (0 ~ 9,
, #)
(default = Not Assigned)
22-11-02 * Target Number
Enter the destination number to which the DID is to be sent.
Maximum of 8 digits (0 ~ 9,
, #, @)
(default = Not Assigned)
20-09-02 * Caller ID Display
Per class of service this allows or denies the stations from receiving
the caller ID name/number that the Telco is sending in.
0 = OFF (Caller ID NOT displayed.)
1 = ON (Caller ID is displayed.)
(default = 0)
20-07-26 * Dial In Mode Switch
Per class of service this allows or denies the stations ability to control
the DDI switching.
0 = OFF (Station cannot control DDI
switching.)
1 = ON (Station can control DDI
switching.)
(default = 0)
15-07-01 * Programmable Function Keys
This program is used on a per station basis to assign different function
keys to the Multiline Terminals. Function key (88) is used to control
the night mode switching change per DID.
One key will control one specific DID. Multiple keys are needed to
control multiple DID's.
88 = Dial In Mode Switching
(Refer to the programming manual for
the default values and for all other
available options in this command.)
Operation
None
ISSUE 2.0
SL1100
Features and Specifications Manual 1-467
