NEC SL1100 - Page 225

NEC SL1100 Issue 6.0
Networking Manual 10 - 13
10-12-09
CPU Network Setup
– IP Address
Assign the IP Address of
the VoIPDB.
0.0.0.0 ~ 126.255.255.254
128.0.0.13~191.255.255.254
192.0.0.1~223.255.255.254
Default is 172.16.0.10
X
10-12-10
CPU Network Setup
– Subnet Mask
Define the Media
Gateway Subnet Mask
Address.
128.0.0.0
192.0.0.0
224.0.0.0
240.0.0.0
248.0.0.0
252.0.0.0
254.0.0.0
255.0.0.0
255.128.0.0
255.192.0.0
255.224.0.0
255.240.0.0
255.248.0.0
255.252.0.0
255.254.0.0
255.255.0.0
255.255.128.0
255.255.192.0
255.255.224.0
255.255.240.0
255.255.248.0
255.255.252.0
255.255.254.0
255.255.255.0
255.255.255.128
255.255.255.192
255.255.255.224
255.255.255.240
255.255.255.248
255.255.255.252
255.255.255.254
255.255.255.255
default is 255.255.0.0
X
10-12-11
CPU Network Setup
- NIC Setup
Define the LAN interface
speed and mode of the
VoIP application
supported.
0 = Auto Detect
1 = 100Mbps, Full Duplex
2 = 10Mbps, Full Duplex
3 = 1Gbps, Full Duplex
default is 0
X
Program
Number
Program Name
Description/
Comments
Assigned Data 1 2 3
