NEC SL1100 Issue 6.0
Networking Manual 13 - 41
Paging across the network – Internal and External
A user can perform and Internal, External, or Combined page to any system in the SL
Net network. To page a remote SL Net system, follow the operation below.
Internal Page – Dial internal paging access code (701 at default) + # + two digit
system ID code (01~04) + two digit Page Zone (00~32). The following is an example
of paging internal zone 1 in remote system 1. User goes off hook and dials 701 + # +
01 + 01 and begins paging. When the user is finished paging, go back on hook to
end the page.
External Page – Dial the external paging access code (703 at default) + # + two digit
system ID code (01~04) + single digit external zone (0~3). The following is an
example of paging external zone 1 in remote system 1. User goes off hook and dials
703 + # + 01 + 1 and begins paging. When the user is finished paging, go back on
hook to end the page.
Combined Page – Dial the combined paging access code (*1 at default) + # + two
digit system ID code (00~04) + single digit external zone number (0~3).
Program Site A Site B Notes
11-12-19 NA NA Default internal page code is 701
11-12-20 NA NA Default external page code is 703
11-12-24 NA NA Default combined page code is *1
31-02-01 NA NA Per site assign phones to an Internal
Paging group.
By default the first 16 ports are in group
1.
31-04-01 NA NA Per site assign each External Paging
zone to an external paging group.
By default Zone 1 = Group 1, Zone 2 =
Group 2, and Zone 3 = Group 3.
31-07-01 NA NA Per site assign External Paging group
(0~3) to an Internal Paging group (0~32)
to be used for combined paging.
By default all External Groups are set to
Internal Page group 1.
