Item
No.
Item Input Data Default
08 OFF Minimum Time 1 ~ 255 (30 + 30 ~ 7680 ms) Refer below
09 OFF Maximum Time 0 ~ 255 (30 + 30 ~ 7680 ms) Refer below
12 Frequency No. 1 1 ~ 8
(Frequency Table No. set by 80-07)
Refer below
13 Frequency No. 2 0 ~ 8 (0 = Not Used)
(Frequency Table No. set by 80-07)
Refer below
14 Twist Level 0 ~ 10 (1 dB ~ 10 dB)
(0 = Not Used)
Refer below
Default
Item Name Type 1 (DT) Type 2 (BT) Type 3 (RBT) Type 4 Type 5
1 Detect Level 0 (- 25 dBm) 0 (- 25 dBm) 0 (- 25 dBm) 0 0
2 Min. detect level 15 (- 25 dBm) 15 (- 25 dBm) 15 (- 25 dBm) 0 0
3 S/N ratio 4 (- 20 dB) 4 (- 20 dB) 4 (- 20 dB) 0 0
4 No tone time 132 (3990 ms) 132 (3990 ms) 132 (3990 ms) 0 0
5 Pulse Count 1 1 1 0 0
6 ON min. time 9 (300 ms) 12 (390 ms) 25 (780 ms) 0 0
7 ON max. time 0 20 (630 ms) 40 (1230 ms) 0 0
8 OFF min. time 1 (60 ms) 12 (390 ms) 83 (2520 ms) 0 0
9 OFF max. time 1 (60 ms) 20 (630 ms) 115 (3480 ms) 0 0
12 Frequency No 1 1 3 2 1 1
13 Frequency No 2 2 4 3 0 0
14 Twist Level 0 0 0 0 0
Conditions
None
Feature Cross Reference
None
SL1100 ISSUE 6.0
2-458 Program 80 : Basic Hardware Setup for System
