Guide to Feature Programming
VoIP Settings:
Program
Number
Program Name/Description
Input Data
Default
10-12-03
GCD-CP10 Network Setup – Default
Gateway
Assign the default gateway IP address for the
GCD-CP10.
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.254.255.254
192.0.0.1 ~ 223.255.255.254
0.0.0.0
10-12-09
GCD-CP10 Network Setup – IP Address
Set IP address for GPZ-IPLE.
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.255.255.254
192.0.0.1 ~ 223.255.255.254
172.16.0.10
10-12-10
GCD-CP10 Network Setup – Subnet Mask
Define the Media Gateway Subnet Mask
Address.
128.0.0.0 | 192.0.0.0 | 224.0.0.0
|240.0.0.0 | 248.0.0.0 | 252.0.0.0
|254.0.0.0 | 255.0.0.0
|255.128.0.0 | 255.192.0.0
|255.224.0.0 | 255.240.0.0
|255.248.0.0 | 255.252.0.0
|255.254.0.0 | 255.255.0.0
|255.255.128.0 | 255.255.192.0
|255.255.224.0 | 255.255.240.0
|255.255.248.0 | 255.255.252.0
|255.255.254.0 | 255.255.255.0
|255.255.255.128
|255.255.255.192
|255.255.255.224
|255.255.255.240
|255.255.255.248
|255.255.255.252
|255.255.255.254
|255.255.255.255
255.255.0.0
10-19-01
VoIP DSP Resource Selection
Select type of VoIP ETU DSP Resource. This
program setting has no affect on the terminal/
trunk port assignment or usage.
0 = Common use for both IP
extensions and trunks
1 = IP Extension
2 = SIP Trunk
3 = CCIS/Networking
4 = Use for NetLink 5
= Blocked
6 = Common without Unicast
Paging
7 = Multicast Paging
8 = Unicast Paging
Resource 1 = 1
Resource
2 ~ 256 = 0
15-05-50
IP Telephone Terminal Basic Data Setup –
Peer to Peer Mode
On a per station basis enable or disable Peer to
Peer mode.
0 = Disable
1 = Enable
1
84-06-01
PVA Data Setting – RTP Port Number
Define the Media Gateway starting RTP Port
Number.
0 ~ 65535
10020
84-06-02
PVA Data Setting – RTCP Port Number
Define the Media Gateway Starting RTCP Port
Number. The RTCP Port Number has to be the
(RTP port number + 1).
RTP Port Number + 1
10021
