Nederman N Series User Manual

N16/24/27/29/40
EN
1Preface
Thank you for using a Nederman product!
The Nederman Group is a world-leading supplier and
developer of products and solutions for the environ-
mental technology sector. Our innovative products
will filter, clean and recycle in the most demanding of
environments. Nederman's products and solutions will
help you improve your productivity, reduce costs and
also reduce the impact on the environment from in-
dustrial processes.
Read all product documentation and the product iden-
tification plate carefully before installation, use, and
service of this product. Replace documentation imme-
diately if lost. Nederman reserves the right, without
previous notice, to modify and improve its products
including documentation.
This product is designed to meet the requirements
of relevant EC directives. To maintain this status, all
installation, maintenance, and repair is to be done
by qualified personnel using only Nederman original
spare parts and accessories. Contact the nearest au-
thorized distributor or Nederman for advice on tech-
nical service and obtaining spare parts. If there are
any damaged or missing parts when the product is de-
livered, notify the carrier and the local Nederman rep-
resentative immediately.
2Safety
2.1Classification of important informa-
tion
This document contains important information that
is presented either as a warning, caution or note, ac-
cording to the following examples:
WARNING!Risk of personal injury
Warnings indicate a potential hazard to the
health and safety of personnel, and how that
hazard may be avoided.
CAUTION!Risk of equipment damage
Cautions indicate a potential hazard to the
product but not to personnel, and how that
hazard may be avoided.
NOTE!
Notes contain other information that is import-
ant for personnel.
3Description
N16/24/27/29/40 are centrifugal fans mainly de-
signed for use with Nederman extraction products
and ideal as an extractor for welding fumes, steam,
dust or for providing fresh air during work in confined
and enclosed spaces. Compact and easy-to-use fans
for both indoor and outdoor use.
3.1Measurements
See Figure1 to Figure3.
NOTE!
Measurements may differ due to updated mo-
tors.
3.2Pressure drop diagrams
See Figure9 to Figure12.
A Total pressure
B Static pressure
C Total pressure (1,1 kW, 1.5 hp)
D Static pressure (1,1 kW, 1.5 hp)
E Total pressure (1,5 kW, 2.0 hp)
F Static pressure (1,5 kW, 2.0 hp)
G Total pressure (2,2 kW, 3.0 hp)
H Static pressure (2,2 kW, 3.0 hp)
3.3Technical data
Technical data
Motor power See product label
Motor speed See motor label
Voltage/Phase See motor label
Frequency See product label
Rated current See motor label
Temperature –30°C to +40°C (–22°F to +104°F)
Airflow temperature max +60°C (+140°F)
