nedis AHDS204CWT4 User Manual

Brightness
Contrast
Chroma
Saturation
AHD
TVI
AUTO
CVI
Click and drag in bottom right image to zoom in
not applicable with our cameras
Select date and camera, search for made recordings in bottom timeline
Play / Pause Play / Pause current video
Stop Stop the video, all screens close
Fast Forward / Rewind Video Fast Forward / Rewind
Slow / Fast Play the video at the speed of 1X/2X/4X/8X/16X
Screen splitting mode Watch 4 cameras simultaneously
Backup Backup recordings on USB hard disk
Capture Save still frame of the selected channel
Full Screen Single-click to enter full screen
Electronic zoom Use the thumbnail on the bottom right corner to select an area to zoom in to
Exit Playback Return to preview page
Image Color
Video Mode Settings
Electronic Zoom
PTZ control
Video Query
Main Menu
Backup
Record
Conguration
System Setting
Basic / Manual /
Event
Schedule
Output Mode
Channel default = ch. 1, select which channel to set.
Stream type video = video only, composite = video and audio
Video quality set quality (higher quality = larger les)
Resolution automatically dened by the camera
Bit rate limit choose preset value or set manually
Frame rate choose any value, default is "full frame rate";
Channel Select the camera for which to set the recording schedule
Select the desired type of recording (No, Common or Motion)
Click and drag to set the schedule for the entire week
Copy the selected schedule to other cameras if needed.
Menu Output
Camera Name
Camera Mosaic
Video Loss
Motion detection
Color Settings
Menu Transparency
Screen Saver Time
Resolution
Output Cong
4
Shown on each channel display
Dene up to 4 areas which are blocked in
recording (security/privacy)
Set the required action when signal loss is
detected
Set sensitivity
Set the required action(s) when motiomn is
detected: recording one or more channels,
showing fullscreen
Area setting (motion mask): only movement in
the highlighted areas triggers recording
Set brightness, contrast, chroma and saturation
for each channel individually
Set the transparency of menu item background
Set the time after which the screen automatically
switches o
Set the resolution sent over VGA and HDMI output
