Connections AUX input/output
SPDIF input
SPDIF output
Micro USB
Main parts (image A)
AUX / SPDIF switch
Volume down / previous track
button
On/off / play / pause button
Volume up / next track button
Bluetooth button
Status indicator LED
Mode switch
AUX port
SPDIF input (Tx)
SPDIF output (Rx)
Micro USB charging port
Main parts (image B)
Stereo audio cable 2x RCA male to
3.5 mm female
3.5 mm to 3.5 mm audio cable
male to male
USB charging cable
SPDIF Optical Audio Cable male
to male
Safety instructions
-
WARNING
• Ensure you have fully read and understood the instructions in this document
before you install or use the product. Keep this document for future reference.
• Only use the product as described in this document.
• Do not use the product if a part is damaged or defective. Replace a damaged
or defective product immediately.
• Do not drop the product and avoid bumping.
