DCAM10BK
Car DVR
Description
The car DVR is a device that is mounted to the windscreen of your
vehicle in order to take photos, record videos and play back photos
and videos.
1. Display
2. On/o button
3. Mode button
4. OK button
5. Menu button
6. Left button
7. Right button
8. Lens
9. Infrared light
10. USB connection
11. Mini-HDMI connection
12. Memory card slot (microSD / TransFlash)
13. Speaker
14. Microphone
15. Reset button
16. Windscreen mount
17. Lock button
Buttons
On/o
• Press the button to switch on the device. Press and hold the
button for 3 seconds to switch o the device.
• Photo mode / Video mode: Press the button to switch on or o
the infrared light.
Mode
• Press the button to select photo mode, video mode or playback
mode.
• Menu mode: Press the button to exit the current menu.
OK
• Menu mode: Press the button to conrm selection.
• Photo mode: Press the button to take photos.
• Video mode: Press the button to record videos. Press the button
again to stop recording videos.
• Playback mode: Press the button to play back photos and videos.
Menu
• Photo mode / Video mode: Press the button to access or exit the
menu mode. Press the button again to access the setup menu.
• Playback mode: Press the button to delete or protect les.
• Menu mode: Press the button to go back one step in the current
menu.
Left
• Menu mode: Press the button to move up in the menu.
• Video mode: Press the button to switch on or o the
microphone.
• Playback mode: Press the button to decrease the volume.
Right
• Menu mode: Press the button to move down in the menu.
• Playback mode: Press the button to increase the volume.
Lock • Video mode: Press the button to lock the video.
Use
1. Insert a memory card into the memory card slot.
2. Power the device using a USB connector and car charger.
3. The device starts recording videos automatically and the red
circle in the top left corner starts ashing.
4. If the device does not start recording videos automatically,
make sure that the device is set to video mode. Press the OK
button.
Video mode
Resolution
1920 x 1080 / 1440 x 1080 / 1280 x 720 / 848 x 480 /
640 x 480
Loop Recording O / 1 min / 2 min / 3 min / 5 min / 10 min
Exposure +2.0 to -2.0
Motion Detection O / On
Record Audio O / On
Date Stamp O / On
G-Sensor O / 2G / 4G / 8G
Lane Departure Warning
O / On
Settings: Car type / Sensitivity / Area Choice / Start
Speed / On/O Sound
Card Info Name / Size / Free (Memory)
Photo mode
Resolution
12 MP (4032 x 3024) / 10 MP / 8 MP / 5 MP / 3 MP / 2 MP
(1920 x 1080) / 1.3 MP / VGA (640 x 480)
Sequence O / On (5 consecutive photos)
Quality Fine / Normal / Economy
Sharpness Strong / Normal / Soft
White Balance Auto / Daylight / Cloudy / Tungsten / Fluorescent
ISO Auto / 100 / 200
Exposure +2.0 to -2.0
Anti-shaking O / On
Quick Review O / 2 s / 5 s
Date Stamp O / Date / Date/Time
Playback mode
Delete Delete Current / Delete All
Protect Lock current / Unlock current / Lock all / Unlock all
