d. Remove the PCIe card from the riser by gently pushing up on the bracket and lift the card straight
out of the socket.
3. Install the replacement PCIe card in the riser by aligning the card with the socket, press the card into
the socket and then close the side panel on the riser, if present.
Be sure that you properly align the card in the slot and exert even pressure on the card when seating
it in the socket. The PCIe card must be fully and evenly seated in the slot.
If you are installing a card in the bottom slot and cannot see the card socket well,
remove the top card so that you can see the card socket, install the card, and then
reinstall the card you removed from the top slot.
4. Reinstall the riser:
a. Align the riser with the pins to the side of the riser socket, lower the riser down on the pins.
b. Push the riser squarely into the socket on the motherboard.
c. Rotate the latch down flush with the sheet metal on the riser.
== Step 4: Replace the mezzanine card
The mezzanine card is located under riser number 3 (slots 4 and 5). You must remove that riser to access
the mezzanine card, replace the mezzanine card, and then reinstall riser number 3. See the FRU map on
the controller module for more information.
You can use the following animation, illustration, or the written steps to replace the mezzanine card.
Animation - Replace the mezzanine card
