NetApp ASA A250 - Page 46

Lever
Latching mechanism
5. Using both hands, grasp the controller module sides and gently pull it out of the chassis and set it on
a flat, stable surface.
6. Turn the thumbscrew on the front of the controller module anti-clockwise and open the controller
module cover.
44
