Steps
1. Locate the boot media using the following illustration or the FRU map on the controller module:
2. Press the blue button on the boot media housing to release the boot media from its housing, and then
gently pull it straight out of the boot media socket.
Do not twist or pull the boot media straight up, because this could damage the socket or the
boot media.
3. Move the boot media to the new controller module, align the edges of the boot media with the socket
housing, and then gently push it into the socket.
4. Check the boot media to make sure that it is seated squarely and completely in the socket.
If necessary, remove the boot media and reseat it into the socket.
5. Push the boot media down to engage the locking button on the boot media housing.
Step 3: Move the NVMEM battery
To move the NVMEM battery from the old controller module to the new controller module, you must perform a
specific sequence of steps.
Steps
1. Check the NVMEM LED:
◦ If your system is in an HA configuration, go to the next step.
◦ If your system is in a stand-alone configuration, cleanly shut down the controller module, and then
check the NVRAM LED identified by the NV icon.
136
