Step Perform on each controller module
Cable e0a and e0b to the cluster interconnect switches with the cluster
interconnect cable:
Use one of the following cable types to cable the UTA2 data ports to your host
network:
An FC host
• 0c and 0d
• or 0e and 0f
A 10GbE
• e0c and e0d
• or e0e and e0f
You can connect one port pair as CNA and one port pair as FC,
or you can connect both port pairs as CNA or both port pairs as
FC.
189
