module from the midplane, and then, using two hands, pull the controller module out of the chassis.
5. Turn the controller module over and place it on a flat, stable surface.
6. Open the cover by sliding in the blue tabs to release the cover, and then swing the cover up and open.
Step 3: Replace the NVMEM battery
To replace the NVMEM battery in your system, you must remove the failed NVMEM
battery from the system and replace it with a new NVMEM battery.
Steps
1. If you are not already grounded, properly ground yourself.
2. Check the NVMEM LED:
◦ If your system is in an HA configuration, go to the next step.
◦ If your system is in a stand-alone configuration, cleanly shut down the controller module, and then
check the NVRAM LED identified by the NV icon.
The NVRAM LED blinks while destaging contents to the flash memory when you halt the
system. After the destage is complete, the LED turns off.
▪ If power is lost without a clean shutdown, the NVMEM LED flashes until the destage is complete,
and then the LED turns off.
▪ If the LED is on and power is on, unwritten data is stored on NVMEM.
This typically occurs during an uncontrolled shutdown after ONTAP has successfully booted.
