Thumbscrew
Cam handle
6. Pull the cam handle downward and begin to slide the controller module out of the chassis.
Make sure that you support the bottom of the controller module as you slide it out of the chassis.
Step 2: Move the boot device
You must locate the boot media and follow the directions to remove it from the old controller and insert it in the
new controller.
1. Locate the boot media using the following illustration or the FRU map on the controller module:
359
