Type of cable… Part number and length Connector type For…
10 GbE network
cable
X6566B-2-R6, (112-00299), 2m
X6566B-3-R6, 112-00300, 3m
X6566B-5-R6 , 112-00301, 5m
Network cable
40 GbE network
cable
40 GbE cluster
interconnect
X66100-1,112-00542, 1m
X66100-3,112-00543, 3m
40 GbE network
Cluster interconnect
100 GbE
network cable
100 GbE
storage cable
X66211A-05 (112-00595), 0.5m
X66211A-1 (112-00573), 1m
X66211A-2 (112-00574), 2m
X66211A-5 (112-00574), 5m
Network cable
Storage cable
This cable applies
to AFF A700 only.
Optical network
cables (order
dependent)
X6553-R6 (112-00188), 2m
X6536-R6 (112-00090), 5m
FC host network
Cat 6, RJ-45
(order
dependent)
Part numbers X6585-R6 (112-
00291), 3m
X6562-R6 (112-00196), 5m
Management network and
Ethernet data
Storage X66031A (112-00436), 1m
X66032A (112-00437), 2m
X66033A (112-00438), 3m
Storage
Micro-USB
console cable
Not applicable Console connection during
software setup on non-Windows
or Mac laptop/console
Power cables Not applicable Powering up the system
4. Review the NetApp ONTAP Confiuration Guide and collect the required information listed in that guide.
ONTAP Configuration Guide
Step 2: Install the hardware
You need to install your system in a 4-post rack or NetApp system cabinet, as applicable.
