BA 1001/1501/2001 US – Edition 2.3 * 12001b110.fm 1-9
Introduction
Description
Unloading mode for the dump bucket.
Location
On the engine cover
Description
Machine serial number label
Location
At the front right of the chassis
Description
Value of sound power level according to the 2000/14/EC standard.
Location
On the engine cover
Description
Always fasten the seat belt if the rollbar is raised!
Do not use the seat belt when the ROPS is lowered to the
stored position.
Location
On the engine cover
Description
1:Attention! Remove starter key and read the Service Manual before servicing the
machine.
2:Hot surface! Do not touch. Keep a safe distance from the machine.
3:Cutting hazard. Cooling fan can cut when rotating. Stop engine before working on the
engine o
r
cooling system.
4:Crushing hazard. Place safety strut in b
locking position on the hydraulic cylinder before
performing maintenance.
Location
On the engine cover
