Introduction
Description
Parking brake
Location (1501H-S, 1001)
Control stand
Description
Dump bucket control mode: dump and lower
Location (1501H, 1001)
On the engine cover
Description
This label indicates the maximum authorized an
gle of inclination for driving on slopes,
whatever the position of the machine.
Location (1001)
Dump bucket
Description
Control identification for swiveling the dump bucket as viewed from the operator seat.
Location (1501S, 2001)
On the engine cover
Description
This label indicates the maximum authorized an
gle of inclination for driving on slopes,
whatever the position of the machine.
Location (1501S)
D
ump bucket
Description
Recommended operating tire pressure.
Location (2001)
2x on mudguards
2x on dump bucket
