User manual
Engine
Engine 12002 RD
Yanmar 4 TNE 106-NS
Wassergekühlter
4 cyl. turbo diesel engine
Capacity4412 cm²
Horsepower in DIN73,4 kw 98 HP
Revolutions per min2100 rpm
Battery12V 120Ah
Diesel tank130 l
Motor oil14 l
Coolant capacity8,7 l
Hydraulic system
Model
Type
Hydraulic system 12002 RD
Pump
Pump capacity
Operating pressure (working and driving)
Operating pressure (swivel unit)
Hydraulic oil cooler
Hydraulic tank (system capacity)
Dozer blade
Dozer blade 12002 RD
Width
Height
max. height above ground level
max. depth below ground level
Bucket (Standard)
Bucket (standard) 12002 RD
Width
Volume
600 mm
255 l
2400 mm
550 mm
620 mm
470 mm
Double axial piston pump
+ gear pump
120 + 120 + 22 l/min
300/320 bar
230 bar
standard
128 l
9707672_user manual_en
- 21 -
