User manual
Stickers 12002 RD
1 Warning symbol
2 Symbol "Read operating instructions"
3 Cleaning
4 LWA 101
6 Lubricant recommendations
7 Dozer blade up/down (windshield)
8 Boom up/down, Bucket open/closed, Horn (windshield)
9 Travel right, forward, reverse (windshield)
10 Travel left, forward, reverse, (windshield)
11 Stick out/in, Swing (swivel) left/right (windshield)
12 Identification plate with CE-Symbol
13 Euro Test
14 Direction arrows (left and right on the guard)
15 Fastening points for lifting the excavator (swiveling console and
right and left
on dozer blade)
16 Tie down points (swiveling console and left and right on dozer
blade)
17 Smbol "Danger" (Do not open while engine is runing)
18 Diesel
19 Hydraulic oil
20 Attention hydraulic tank under pressure
9707672_user manual_en
- 24 -
