Neuson 12002 RD - Component Designations

User manual
4 Component Designations
1
7
2 3 16,17 8,9
4 5 6
10
11
12
20
18
1
2
3
4
5
6
7
8
9
10
14 19
11
12
13
14
15
16
17
18
19
20
15 20 13
Component Designations 12002 RD
Bucket stick
Bucket stick cylinder
Boom
Cab
Driver's seat
Engine cover
Bucket cylinder
Left control lever
Right control lever
Backhoe bucket
Boom cylinder
Steering control console
Dozer blade
Undercarriage
Chassis
Left drive lever
Right drive lever
Traveling drive
Protective cover for track tensioner
Eyes for lifting and tying down excavator
