User manual
13 Starting the excavator
o
Adjust driver's seat (spring tension, position, seat
back).
Place all switches and levers in their neutral
position.
Insert the key in the ignition and
turn.
o
o
Starting procedure
Accelerator in idling position.
Step 1:
NOTE:
Step 2:
Step 3:
o
Ignition on
Oil pressure and charge indicator lights should
come
on--warning light test
Turn key to warm up glow plug, hold key for
about 15
seconds
Start
Release ignition key as soon as the engine is
running.
The ignition key automatically returns to the
ON
position.
NOTE:
Do not engage the starter for more than 10 seconds at a
time.
If the engine does not start, pause for at least 30 seconds to
let the
battery recover before trying again.
Leave the key in the ON position during operation. If the
key is
turned to "O", the engine is turned off.
ATTENTION:
ATTENTION:
Indicator lights (oil pressure and charge
indicator) should go out after starting.
If they do not go out, or if one comes on
during
operation, stop the engine and have
maintenance personnel or the repair shop
look into the problem.
Let the engine warm up for approx. 5
minutes
to allow the hydraulic oil to get hot.
ATTENTION:
9707672_user manual_en
- 47 -
