User manual
20.4 Traveling drive
Change drive oil
Change the drive oil on the outside of the drive
unit
1) Put drive in the position shown
Open top and bottom screw plugs
Drain oil, collect in a container
Close bottom screw plug properly
2) With the drive in the position shown
Open middle screw plug
Refill with fresh oil in the top opening until it comes
out of the
middle opening
Close both openings properly
ATTENTION: Dispose of used oil in accordance with
environmental laws.
9707672_user manual_en
- 67 -
