New Focus 1421 - Page 7

Fig. 1
Front, side, and rear views of the Model 1421
and 1422 amplifier modules.
4.26 (109.2)
Power Connector
±15 V
Fastener for use
with Model 10XX or
14XX detectors
K-connector
Male Output
Connector
K-connector
Female Input
Connector
1.51
(38.14)
3.74 (94.8)
2.00
(50.8)
2.00
(50.8)
Model 10XX or
14XX Detectors
(Not Included)
.05-20 GHz Amplifier
1421
7
