3-CONTROLSANDINSTRUMENTS
StandardISOcontrolpattern
RAIL14SSL0314FA1
Thechartbelowwillgiveadescriptionofthecontrolleverfunctions.Theleft-handcontrolleveris
representedbytheletter(A)andtheright-handcontrolleverbyletter(B).
(A)Left-handcontrollever
(1)Driveforward.
(2)
Turnright,clockwiserotate.
(3)
Reverse.
(4)Turnleft,counter-clockwiserotate.
(B)Right-handcontrollever
(5)
Loaderarmlower.
(6)
Dumpbucket.
(7)
Loaderarmraise.
(8)Rollbackbucket(curl).
NOTE:ThestandardISOcontrolpatternusestheleft-handcontrolleverforgrounddrivefunctionsandtheright-hand
controlleverforloaderarmandbucketfunctions.
NOTICE:Donotoperatetheunituntilthehydraulicoilisatsufcientoperatingtemperature.
Electro-hydrauliccontrolhandleadjustment
Thecontrolleverscanbeadjustedforoperatorcomfort.
1.Adjusttheheightofthecontrolleverbylooseningtwo
nuts(1)andmovingthecontrolleverassemblyinto
oneofthethreenotchesprovidedinthemounting
bracket.Tightenthetwonuts(1).
2.Adjusttheforwardandrearwardpositionofthecontrol
leverbylooseningtwohandknobs(2)andslidingthe
controlleverassemblytothedesiredposition.Tighten
thehandknobs(2).
RAIL14SSL0329AA1
3-13
