NEW POS Technology limited
Product manual
NEW POS Technology limited
Product manual
6210 is a powerful PCI approval, EMV approval , with extraordinary
performance in data intensive, multiple applications and EMV transactions.
PINPAD
Product Introduction
6210 Figure
Antenna
inductive zone
Top view
Back view
LCD display
Key pad
User smart card slot
Magnetic stripe card
Back cover
Rubber pad
Tag Label
Barcode
Label
USB Port
Stylus pen
Lanyard hole
Interface Figure
Parts function description
Antenna inductive zone:
The zone for tapping contactless card.
LCD display: 2.8 inch and 320*240 TFT LCD. Optional signature
capture function.
Key pad: 10 alphanumeric keys, 6 functional keys.
User smart card slot: Supporting EMV card with contact surface facing up.
Magnetic stripe card : 1/2/3 Tracks, bi-directional swiping with the magnetic
stripe facing LCD.
Cable: The cable is used to connect the pinpad to other device.
Back cover: Remove the cover to install battery or SAM card.
Tag label: Showing model name, rated device parameter.
Barcode Label: Indicating device serial number.
Rubber pad: Two pads, anti-vibration/non-slip.
Lanyard hole : Can be installed lanyard, easy to carry.
Signature pen : Electronic signature pen.
USB Port: USB communication interface.
Cable
