Newage Pro Series - Page 2

2
INDEX
Product Overview:
Safety Warning - 3
Tools Needed - 5
Included Quantities - 6
Spare Parts - 7
Weight Capacity - 8
Installation Overview - 9
Installation Overview:
Installation Options - 10
Wall Conguration: Installation Location - 11
Ceiling Conguration: Installation Location - 12
Installing Wall Brackets & Back Beam - 13, 14
Wall Conguration: Installing Pad Eye Plate - 15
Perimeter Beam & Cable Assembly-16
Ceiling Conguration: Installing Pad Eye Plate - 17
Perimeter Beam & Cable Assembly - 18
Cable Assembly - 19
Cross Support Assembly - 21
Grid Supports & Wire Grids - 21, 22
Installation Tips
Irregular Joist Spacing - 23
Fastening to Engineered Joists - 26
Connecting Wall Mounted Shelf Horizontally - 27
Connecting Wall Mounted Shelf Vertically - 28
Connecting Corner Wall Mounted Shelf - 29,30
