DROP DOWN ATTACHMENT INSTALLATION – NLE3BDDA (OPTIONAL EXTRA)
1. Remove the standard diffuser on the main product by undoing the two screws.
2. Install the Drop Down Attachment on the main luminaire body & secure using the two screws.
3. Apply the required emergency legends (supplied with the attachment) to both sides of the attachment.
TESTING FOR EMERGENCY LUMINAIRES
Recommended routine test procedures in line with BS 5266 & BS EN 50172:
Monthly Functional Test
• Simulate a mains supply failure by isolating the circuit (ensuring if it is safe to do so) or by way of a test key switch if
fitted into the circuit.
• Do this for a period of time sufficient to check that the light source illuminates from the battery supply.
• Once complete, ensure the normal supply is restored & that the green LED charge indicator illuminates.
• Log result/comments in the Testing Log Book.
Annual Discharge Test
• Simulate a mains supply failure by isolating the circuit (ensuring if it is safe to do so) or by way of a test key switch if
fitted into the circuit.
• This should be for the full 3-hour rated duration.
• Check that the light source illuminates & remains illuminated for the full rated duration period.
• Once complete, ensure the normal supply is restored & that the green LED charge indicator illuminates.
• Log result/comments in the Testing Log Book.
TESTING LOG BOOK
Luminaire Type: ……………………………… Luminaire Location/No.: ………………………………...
Installed By: ……………………………… Installed Date: ……………………….....................
Contact Details: …………………………………………………………………………………………………………………………..
…………………………………………………………………………………………………………………………..
MONTH
TEST
Signed Date Signed Date Signed Date Signed Date Signed Date
1
FU NCTION AL
2
FU NCTION AL
3
FU NCTION AL
4
FU NCTION AL
5
FU NCTION AL
6
FU NCTION AL
7
FU NCTION AL
8
FU NCTION AL
9
FU NCTION AL
10
FU NCTION AL
11
FU NCTION AL
12
D ISC HA RGE
FIFTH YEARFIRST YEAR SECOND YEAR THIRD YEAR FORTH YEAR
