6.4 Armrests
The wheelchair Magix is equipped with flip back angle adjustable armrests, adjustable in height, tilt, in depth and in width.
To raise the armrest he must pull the front of the armrest up and rotate toward the rear. Vice versa for the
fold.
Attention before folding the armrest always check that nothing impeded its swing. Danger of severing at the
hinge of the armrest!
1 2 Adjusting the height of the armrests:
To adjust the height of the armrests you must:
- Unscrew the screw #1 and remove the seat belt retraint
- Unscrew the screw #2 which is located behind the seat belt restraint
- Remove the armrest support braket by pulling it toward the inside of the wheelchair
- Reposition the bracket of the armrest on the screws spacers at the desired height
- Refit and tighten the screw #2
- Replace the seat belt restraiant with the screw #1 and tighten the screw
Attention before folding the armrest always check that nothing impeded its swing. Danger of severing at the hinge of the armrest!
