BESKAR PEDAL SERVICE MANUAL
Version: 1.0; Date: 14.08.2024
MG-Components GmbH Co. KG / Am Mühlbach 5c / 87487 Wiggensbach / Germany
Email: info@mg-components.de / Web: www.newmen-components.de
Unscrew the end cap from the pedal anti-clockwise using a 5 mm hex key. Unscrew the M4 nut on the outside of the pedal while holding inside with a 6mm hex
key. Attention: The nut of the left pedal is loosened anti-clockwise (right-hand
thread), the nut of the right pedal is loosened clockwise (left-hand thread)!
1 2
