TROUBLESHOOTING
SYMPTOM
CAUSE
CURE
Sensor fails to add to the
network (slow blinking of the
Status LED and no pairing
action seen on the bridge)
Out of range
Add a Z-Wave repeating device (e.g. light module/dimmer) at a location between the bridge and
the sensor.
1. Add a repeater to the network following that device’s instructions.
2. Try to add the sensor to the network again at the desired sensing location.
Improperly removed from
network previously
1. Remove the sensor from the network following the steps in the “REMOVE” table.
2. Try to Add the sensor to the network again.
Sensor drops connection
intermittently
Edge of range
Add a Z-Wave repeating device (e.g. light module/dimmer) at a location between the bridge and
sensor.
FACTORY RESET
Factory Reset should only be used when the primary controller is missing or otherwise inoperable.
ASSOCIATION GROUP INFORMATION TABLE
Group
Profile
Command Classes
Group Name
Max Devices
1
Lifeline
Battery Report, Multilevel Sensor Report, Device Reset
Locally Notification
Lifeline
1
2
Sensor
Multilevel Sensor Report
Temperature Reports
5
3
Sensor
Multilevel Sensor Report
Humidity Reports
5
4
Sensor
Basic Set
Temperature Driven Basic Sets
5
5
Sensor
Basic Set
Humidity Driven Basic Sets
5
6
Sensor
Battery Report
Battery Reports
5
Z-WAVE CONFIGURATION TABLE
Parameter
Description
Length
(Bytes)
R/W
Default
Value
Valid Values
1
Time between Battery Reports (hours)
1
R/W
0
Range: 1–127 hours
0 = Do not send periodically
2
Send BASIC SET ON above this temperature (See #20)
1
R/W
121
Range: 15° – 120° F
121 = Disabled
3
Send BASIC SET ON below this temperature (See #20)
1
R/W
121
Range: 15° – 120° F
121 = Disabled
4
Send BASIC SET OFF above this temperature (See #20)
1
R/W
121
Range: 15° – 120° F
121 = Disabled
5
Send BASIC SET OFF below this temperature (See #20)
1
R/W
121
Range: 15° – 120° F
121 = Disabled
6
Send multiple attempts for all BASIC SET commands
1
R/W
0
1-5 = Number of extra attempts sent every minute after
first send
0 = Disabled
7
Temperature Units
1
R/W
1
1 = Fahrenheit
0 = Celsius
8
Association Group1 – Temperature delta auto send threshold
1
R/W
10
Range: 1 - 200
Parameter is in tenths of degrees.
9
Association Group1 – Periodic temperature send interval
1
R/W
0
Range: 1-120 minutes
0 = Disabled
10
Association Group2 – Temperature delta auto send threshold
1
R/W
10
Range: 1 - 50
0 = Disabled
Parameter is in tenths of degrees.
11
Association Group2 – Periodic temperature send interval
1
R/W
0
Range: 1-120 minutes
0 = Disabled
12
Send BASIC SET ON above this humidity
(See #20)
1
R/W
0
Range: 1–100%
0 = Disabled
13
Send BASIC SET ON below this humidity (See #20)
1
R/W
0
Range: 1-100%
0 = Disabled
14
Send BASIC SET OFF above this humidity (See #20)
1
R/W
0
Range: 1-100%
0 = Disabled
15
Send BASIC SET OFF below this humidity (See #20)
1
R/W
0
Range: 1-100%
0 = Disabled
16
Association Group1 – Humidity delta auto send threshold
1
R/W
5
1-50%
17
Association Group1 – Periodic humidity send interval
1
R/W
0
Range: 1-120 minutes
0 = Disabled
18
Association Group3 – Humidity delta auto send threshold
1
R/W
5
Range: 1-30%
0 = Disabled
19
Association Group3 – Periodic humidity send interval
1
R/W
0
Range: 1-120 minutes
0 = Disabled
20
BASIC SET options for temperature and humidity
1
R/W
1
Configuration Register Combinations:
1 = Enable Registers 2, 5, 12 15
2 = Enable Registers 2, 5, 13, 14
3 = Enable Registers 3, 4, 12, 15
4 = Enable Registers 3, 4, 13, 14
21
Temperature Offset
1
R/W
0
Range: -7° to 7° F
22
Humidity Offset
1
R/W
0
Range: -7% to 7%
23
Humidity Filter Time Constant
1
R/W
30
Range: 1 – 60 minutes
© 2017 Ingersoll Rand
Rev. 20171002
