Nexus 21 L-65 - Page 14

14
A1
A21
2
3 4
DC AC
To Power Outlet
Lift Column - Port 1
Backup Switch - Port A1
Contact Closure/IR/RF/IP Controls - Port A2
6a. Connect one end of the Motor Cable to the Lift Column and the other end to Port #1 on the Control Box.
6c. Connect to the Power Cord to the AC Port and the Backup Switch to Port A1 on the Control Box.
