Nexus 1000 - Motor Installation; Hand Control and Cable Connections

NOTE:Beforeinstallingmotor,plughand
pendantandHi/Lowmotorcableintomotor
asshown
14.Connectthe9Vbattery(soldseparately)tothe
 batterycliponthemotor.Itisstoredintherecess
 underthemotorcover.Withthisbatteryinstalled,
 themotorcanbeoperatedintheeventofapower
 failure.
15. Toinstallmotor,removelockingcapsontopof
 themotor.
Motor Installation
HAND CONTROL
TheCompetitorbedcomeswithahandcontrolthatwill
illuminatewhenthebedispluggedintoagroundedor
polarizedwalloutlet,orwith9Vbattery(soldseparately)
installedinthehandcontrol.Thehandcontrolwill
illuminateaslongasthewallorbatteryhaspower.With
thisbatteryinstalled,themotorcanbeoperatedtoreturn
thesleepsurfacetothehorizontalpositionintheeventof
apowerfailure.
