1.1.1 Exploded View and Mechanical Data/Text Identification
1.1.2 User Controls & Indications
Display board assembly
mounted on removable door
Printer
Space for Internal
12AH Battery Set
Power Supply Board
Motherboard
Expansion Motherboard
Loop Cards
Expansion Cards
A1535 8 way relay
A1536 8 way alarm
Loop Cards
Network Card
