NF F8 Series - 25 Channel DMX Functions

V
CH3
Pattern setting
0～255
one pattern per16 value
CH4
Pattern rotation
1～127
Rotation angle selection
128～191
speed adjustment in reverse rotation
192～255
speed adjustment in positive rotation
CH5
Patterns
horizontal
rotation
1～127
Horizontal rotation selection in position
128～255
Horizontal rotation selection in speed
CH6
Patterns vertical
rotation
1～127
Vertical rotation selection in position
128～255
Vertical rotation selection in speed
CH7
Pattern
horizontal
move
1～127
Horizontal move selection in position
128～255
Horizontal move selection in speed
CH8
CH9
Pattern vertical
move
1～127
vertical move selection in position
128～255
vertical moving selection in speed
Pattern size
Pattern scaling
0～63
pattern size selection
64～127
Reduce speed selection
128～191
Zoom in speed selection
192～255
zoom speed selection
CH10
Pattern
gradually
drawing 一
1～127
Adjustment in gradually drawing speed
Pattern
gradually
drawing 二
128～255
CH11
Scanning speed
0～127
Adjustment in scanning speed
Point effect
128～255
CH12
Color mode
0～63
Fixed color selection
64～127
Speed selection in Color change effect
128～191
Speed selection in flowing Water effect
192～255
Speed selection in gradually drawing
四、●25 Channel functions::
Channel
DMX-512
numerical
value
Controlling
CH1
Laser off
0～41
Laser off
Automatic
42～83
manual control
84～125
running animation effect
126～167
running light beam effect
Music Control
168～209
running light beam effect
210～251
running animation effect
252～255
manual control
CH2
Pattern A group
selecting
0～255
one Pattern group per 32 value
