32 NIBE BA-SVM 10-200
Current menus
Menu Name Factory setting
5.1.12 start tillsats -400
5.3.2 minimum running
time
12 hrs
lowest temperature 55 °C
shunt amplification 1,0
shunt waiting time 30 secs
Connections, accessory card
Input Function
X2:21-22 boiler sensor
X2:23-24 external blocking
Output Function
K1 External addition (burner)
permitted
K2 Mixing valve, close
K3 Mixing valve, open
K4 External circulation pump
Step controlled additional heat (AXC 40)
Address (dipswitch setting): 1110 1000
• When DM is below the set start DM the addi-
tional heat is started and steps in as the DM falls
/ steps out as DM increases.
• Time between step ins = 60 secs.
• Time between step outs = 2 secs.
• Additional heat is only allowed to step out when
heating is permitted and when the additional
heating is permitted in heating mode and the in-
put for blocking is not connected.
Current menus
Menu Name Factory setting
5.3.6 start tillsats -400
diff. between addi-
tional steps
100 GM
max. step 3
Linear/binary
control
Connections, accessory card
Input Function
X2:23-24 Block step controlled additional
heat
Output Function
K1 Step 1
K2 Step 2
K3 Step 3
Hot water circulation (AXC 40)
Address (dipswitch setting): 1001 0000.
Hot water circulation (HWC) GP11.
The circulation pump is active for a set operation and
downtime time during a selected period.
Menu Setting Factory
setting
Notes
2.9.2 Period 1 Off Time when
HWC must
be active
Period 2 Off Time when
HWC must
be active
Period 3 Off Time when
HWC must
be active
Run time 3 min
Downtime 12 min
5.2.4 Activating
hot water
comfort
On
