PIPE CONNECTIONS
INSTALLATION ON RADIATOR VALVE
NOTE
SRV 10 must not be installed outdoors.
1. Insert the batteries
2. SRV 10 goes to installation mode, "P1" is shown in the
display.
3. When the motor has stopped, "P1" is completed and you
can fit the SRV 10 on the radiator valve. When the SRV
10 is installed, press +.
4. Automatic calibration starts. "P2" is shown in the display
once the outer end position is located, after which "P3"
is shown when the extent of movement is tested.
5. Calibration is complete and the temperature is shown
in the display.
Fitting without adapter
Fitting with supplied adapter
Fitting with the ARV 10 (accessory)
9SRV 10 | EN
