Code Description Setting range Default Modify
Modbus
Address
③ Start mode
0: Start directly
1: DC injection brake first
and then start at start freq.
2: Speed tracking and start
0 ○ 0200H
F1.01 Start freq. 0.10~60.00Hz 0.50Hz ○ 0201H
F1.02
Start freq. hold
time
0.0~10.0s 0.0s ○ 0202H
F1.03
②
DC brake
current at start
G: 0.0~100.0% rated
current
0.00% ○ 0203H
F1.03
③ DC brake
current at start
G: 0.0~100.0% rated
current
0.00% ○ 0203H
P: 0.0~80.0% rated current
F1.04
DC brake time
at start
0.0 ～ 30.0s 0.0s ○ 0204H
F1.05 Acc./Dec. mode
0:
Linear
1:
S-curve
0 ○ 0205H
F1.06
Time of S-curve
initial stage
10.0 ～ 50.0% (Acc./ Dec.
time) F1.06+F1.07≤90%
30.00% ○ 0206H
F1.07
Time of S-curve
rising stage
10.0~80.0% （ Acc./ Dec.
time ） F1.06+F1.07≤90%
40.00% ○ 0207H
F1.08 Stop mode
0: Deceleration to stop
0 × 0208H
1: Coast to stop
2: Deceleration +DC
braking
F1.09
DC brake
trigger
frequency at
stop
0.00 ～ 550.0Hz 0.00Hz ○ 0209H
F1.10
DC brake
waiting time at
stop
0.00 ～ 10.00s 0.00s ○ 020AH
F1.11
②
DC brake
current at stop
0.0~100% rated current
0.00%
○ 020BH
