NE200&300 Quick Start Guide
32
Code Description Setting range Default Modify
M
odbus
Address
proportional gain 2
F3.04
Speed loop integral
time 2
1~3000 200 ○ 0404H
F3.05
Switching
frequency 2
0.0 ～ 60.00Hz 10.00Hz ○ 0405H
F3.06
Speed loop filter
time constant
0 ～ 500ms
2ms
②
3ms
③
○ 0406H
F3.07
Current loop
proportional
coefficient
0 ～ 6000 3000 ○ 0407H
F3.08
Current loop
integral coefficient
0 ～ 6000 1500 ○ 0408H
F3.09
VC Slip
compensation
0.0 ～ 200.0% 100.00% ○ 0409H
F3.10
② Torque control
0:Torque control
Disabled
0 ○ 040AH
1:Torque digital
setting(F3.11)
2:AI1 3:AI2
4:Reserved
5:communication
6:keypad
potentiometer
③ Torque control
0:Torque control
Disabled
1:Torque digital
setting(F3.11)
2:AI1 3:AI2
4:Pulse
5:communication
6:keypad
potentiometer
0 ○ 040AH
F3.11
Torque digital
setting
0.0 ～ 200.0% 50.00% ○ 040BH
F3.12 Torque control 0: digital 0 ○ 040CH
