Nidec NE200 Series User Manual

NE200&300 Quick Start Guide
36
Code Description Setting range Default Modify
Modbus
Address
3: 1.2 power decreasing
torque
4: Multiple dots V/F
F4.01 V/F freq. F1 0.0 ～ F4.03 10.00Hz × 0501H
F4.02
V/F voltage
V1
0.0 ～ 100.0% 20.00% × 0502H
F4.03 V/F freq. F2 F4.01 ～ F4.05 25.00Hz × 0503H
F4.04
V/F voltage
V2
0.0 ～ 100.0% 50.00% × 0504H
F4.05 V/F freq. F3 F4.03 ～ F0.10 40.00Hz × 0505H
F4.06
V/F voltage
V3
0 ～ 100.0% 80.00% × 0506H
F4.07 Torque boost
0.0%: Auto boost
0.00% ○
0507H
0.1 ～ 30.0%: Manual
boost
F4.08
Manual
torque boost
cutoff point
0.00 ～ 60.00Hz 50.00Hz ○ 0508H
F4.09
Slip
compensation
coefficient
0.0 ～ 200.0% 0.00% ○ 0509H
F4.10
Slip
compensation
filtering time
0.01 ～ 2.55s 0.20s ○ 050AH
F4.11
V/F
separation
control
voltage
source
0: disabled
1: Digital setting (F4.12)
2: AI1
3: AI2
4: Pulse
5: communication
0 × 050BH
F4.12
V/F
separation
voltage digital
setting
0V ～ max output voltage
38
0V
○ 050CH
F4.13 V/F 0.0s ～ 1000.0s 0.0s ○ 050DH
