Nikro DV15360 - 15 GALLON TANK ASSEMBLY; #DV15360 WIRING DIAGRAM

11
15 GALLON TANK ASSEMBLY
#DV15360 WIRING DIAGRAM
PC NO PART NO PART NAME QTY
1 860802 TANK 1
2 860804 FRONT CASTER 2
3 860584 AXLE ASSEMBLY 1
4 520227 REAR WHEEL 2
5 860220 SIDE HANDLES 2
6 860803 LID LATCH 2
7 860550 HANDLE 1
8 861292 3” INTAKE 1
Not
Shown
861288
DOWN TUBE COUPLER
ASSY
