7
4.2 Mounting of spray
lance and Click & Clean
nozzles
2. Attach the nozzle.
Warning: When
attaching the Click &
Clean nozzles, the
pawl on the side
of the spray lance (6)
should come out again.
Note: The Torna-
do
®
PR nozzle (8)
and the foam sprayer (10) fea-
ture a swivel lock, which must
be positioned in the hole in the
Click & Clean spray lance (6).
Press the pawl to detach the
Click & Clean nozzle.
6
7
1. Push the spray lance (6) into
the spray gun (7) and screw
it on.
Note: The spray lance (6) has a
built-in low pressure nozzle that
can be used for fl ushing away
dirt.
4.3 Water connection
IMPORTANT! Only use wa-
ter without any impurities. If
there is a risk of running sands
in the inlet water (i.e. from
your own well), an additional
fi lter (106411231) should be
mounted.
1. Let the water run through the
water hose before connecting
it to the machine to prevent
sand and dirt from penetrat-
ing the machine.
Note: Check that the fi lter is
fi tted in the water inlet pipe
and that it is not clogged up.
2. Connect the water hose to
the water supply by means
of the quick connector (inlet
water, max. pressure: 10 bar,
max. temperature: 40°C).
3. Turn on the water.
An ordinary 1/2" garden hose
of min. 10 m and max. 25 m
will be suitable.
NOTE: Connection to the public
mains according to regulations.
