Nilfisk-Advance E130.3 User Manual

14
D
Service / Repair.
Disassembly / assembly of the motor / pump unit.
1. Now there is free access to the motor / pump unit. (Fig 14)
2. X-TRA: Remove the internal hose from the pump by removing the U-pin (Fig 15)
Be careful not to loose the spring and the Non Return Valve (NRV) from the water outlet.
Fig. 15
Fig. 14

Nilfisk-Advance E130.3 Specifications

General

Brand	Nilfisk-Advance
Model	E130.3
Category	Pressure Washer
Language	English
