Nilfisk-Advance SC450 Service Manual

General Information
13
Service Manual – SC450
Control Panel Battery Version
Green LED - charged battery
Yellow LED - semi-discharged battery
Red LED - discharged battery
Brush switch Vacuum system switch
Electronic battery
charger
Lead (WET) or gel (GEL)
battery selector
max.2%
Battery charge
LEDs indicator
Green warning light
(the battery charger is
on and batteries are
charged)
Yellow warning light
(the battery charger is
on and batteries are
semi-discharged)
Battery charge
LEDs indicator
Green warning light
(the battery charger is
on and batteries are
charged)
Yellow warning light
(the battery charger is
on and batteries are
semi-discharged)
Red warning light (the battery
charger is on and it is charging
the batteries)
Brush enabling
push-button
Brush enabling
push-button
Brush enabling
push-button
Brush enabling
push-button
P200004
