Squeegee System 118Service Manual – SCRUBTEC R466 ... FOCUS II Micro Rider
Component Location
• Squeegee
• Squeegee blades
• Squeegee holder
• Mounting handwheels
• Squeegee adjustment
• Actuator (M6)
• Squeegee lifting cable
5
4
2
1
4
3
7
2
Actuator (M6)
Squeegee lifting
cable
Squeegee holder
Mounting hand-
wheels
Squeegee
Squeegee adjust-
ment
Mounting hand-
wheels
Squeegee blades
P100753
