Squeegee System 119Service Manual – SCRUBTEC R466 ... FOCUS II Micro Rider
Maintenance and Adjustments
Squeegee cleaning
Note: The squeegee must be clean and its blades must be in good conditions in order to get a
good drying.
Warning! It is advisable to wear protective gloves when cleaning the squeegee because there
may be sharp debris.
1. Drive the machine on a level oor.
2. Insert the ignition key and turn it to “I”.
3. Lower the squeegee by pressing the vacuum system push button .
4. Turn the ignition key to “0”.
5. Disconnect the vacuum hose from the squeegee.
6. Loosen the handwheels and remove the squeegee.
7. Wash and clean the squeegee. In particular, remove dirt and debris from the compartments (A) and
the hole (B). Check that the front blade (C) and the rear blade (D) are integral and free from cuts and
lacerations; if necessary replace them.
8. Assemble in the reverse order of disassembly.
A
C
D
B
A
D
C
P100754
