Wheel System, Driving 130Service Manual – SCRUBTEC R466 ... FOCUS II Micro Rider
Component Location
• Accelerator pedal (RV1)
• Reverse switch
• Speed adjustment switchers
• Speed indicator LEDS
• Anti-skid control LED
• Driving wheel assembly
• Drive system motor (M3)
• Electromagnetic brake (BRK)
• Driver's seat sensor (SW1)
Accelerator pedal (RV1)
Reverse switch
Anti-skid control LED
Speed adjust-
ment switchers
Speed indicator
LED
P100759
Driving wheel assembly Electromagnetic brake (BRK) Drive system motor (M3) Driver’s seat sensor (SW1)
P100760
