Service Manual – SCRUBTEC R466 ... FOCUS II Micro Rider
Technical Data
General technical data
Description
SCRUBTEC
R 466
-
FOCUS II Micro
Rider
26D
SCRUBTEC
R 471
SCRUBTEC
R 471C
SCRUBTEC
BOOST
®
R4
-
FOCUS II Micro
Rider
28 BOOST
Cleaning width 26 in (660 mm) 28 in (710 mm) 28 in (710 mm) 28 in (710 mm)
Squeegee width 35 in (890 mm)
Solution/clean water tank capacity 21.1 US gal (80 L)
Solution/clean water tank capacity 21.1 US gal (80 L)
Min/max solution ow (with and without Chemical Mixing
System)
0 ÷ 0.8 gpm (0 ÷ 3.0 L/min)
Chemical Mixing System kit detergent concentration settings 0,4% - 0,75% - 1,5% - 2,5%
Rear wheel diameter 9.8 in (250 mm)
Rear wheel specic pressure on the oor (*) 130 psi (0.9 N/mm
2
)
Front steering, driving and braking wheel diameter 8.8 in (225 mm)
Front wheel specic pressure on the oor (*) 72 psi (0.5 N/mm
2
)
Vacuum system motor power 0.56 hp (420 W) (0.9 hp (670 W) optional)
Drive system motor power 0.4 hp (300 W)
Maximum speed 3.7 mph (6 km/h)
Maximum gradient when working 2%
Sound pressure level at workstation
(ISO 11201, ISO 4871, EN 60335-2-72) (LpA)
65 dB(A) ± 3 dB(A)
Machine sound pressure level
(ISO 3744, ISO 4871, EN 60335-2-72) (LwA)
82 dB(A)
83 dB(A)
Vibration level at the operator's arms
(ISO 5349-1, EN 60335-2-72)
< 98.4 in/s
2
(< 2.5 m/s
2
)
Vibration level at the operator's body
(ISO 2631-1, EN 60335-2-72)
< 31.4 in/s
2
(< 0.8 m/s
2
)
Battery compartment size (length x width x height) 14.9 x 21.5 x 11.8 in (380 x 540 x 300 mm)
Battery type
4 6V batteries, 180 Ah C5 (WET)
4 6V batteries, 180 Ah C5 (GEL/AGM)
Standard batteries autonomy 2,5 - 3,5 hours
Total electrical input 60 A
Machine height 48.4 in (1,230 mm)
Machine maximum length 53.5 in (1,360 mm)
Minimum turning radius 59.0 in (1,500 mm)
Machine width without squeegee 26.4 in (670 mm) 29,4 in (748 mm) 31,9 in (810 mm) 28.7 in (730 mm)
Vacuum performance 0.0098 MPa (1,000 mm/H
2
O)
(*) Machines have been tested under the following conditions:
◦ With operator on board (165.3 lb - 75 kg)
◦ Maximum battery size
◦ Maximum brush and squeegee size
◦ Full clean water tank
◦ Optional components installed
◦ Weight on wheels checked
◦ Print on the oor checked on cement for each single wheel
◦ Result expressed as maximum value for front and rear wheels
