Control System 22Service Manual – SCRUBTEC R466 ... FOCUS II Micro Rider
Component Location
• Function electronic board (EB1)
• Display electronic board (EB2)
• Dashboard (EB3)
1
Function electronic
board (EB1)
P100684
3
2
Display electronic
board (EB2)
Dashboard (EB3)
P100685
