Electrical System 44Service Manual – SCRUBTEC R466 ... FOCUS II Micro Rider
Component Location
• Batteries (BAT)
• Battery connections
• Battery charger (CH)
• Electrical panel
• Battery connector (C1)
• Function electronic board (EB1)
3
6
Battery charger (CH)
Battery connector
(C1)
Batteries (BAT)
Battery connections
P100700
4
4
Electrical panel
Function electronic
board (EB1)
P100701
